MT201

Fully managed in-vehicle device for HGV fleets

Safely and effectively connect with your drivers in the field, replace manual processes with digitised workstreams and increase productivity.

For your drivers the cab is their office, and with Teletrac Navman's MT201 you can help them to maintain compliance and complete jobs on time. The device can be configured to include a wide range of applications covering safety, compliance and job management, enabling you to build the digital workflow that your business needs.
The 7" rugged tablet is available as part of a fully managed environment, so you can be confident that your solution will continue to deliver results, without having to manage the complexities of a mobility solution. We do the heavy lifting you, and manage software updates, compatibility and fault resolution.

Improve Safety

Streamline maintenance and driver coaching







Increase Productivity

Automate tasks and streamline job management







Digital Processes

Implement digital processes that improve the day-to-day operations of your business

Manage Compliance

Meet compliance requirements with digital tools





Key Features - Device & Software:

  • Pre-trip inspection checklists
  • Customizable forms
  • Electronic in-cab documents
  • Speed management
  • Real-time route guidance
  • Job management
  • Instant messaging
  • Driver identification
  • Electronic Driver Logs

Key Features - Managed Service:

  • Secured device
  • Automatic updates
  • Service desk access
  • Device management
  • Device provisioning
  • Integration
  • Device warranty
  • Tracking and location

Implementing the Teletrac Navman system has been the best thing we’ve ever done. Teletrac Navman has customised everything to what we need and want. It’s not a case of buying on the shelf and being stuck with the same product. It’s personalised to what we need.

- Leigh Smart, Formula Chemicals

MT201

Technical Specifications

Certifications: CE/CB, FCC/IC, RCM, E-mark, ROHS, WEEE

Water/Dust Ingress: IP54

Shock and Vibration: SAE J1455 standard, up to 20G peaks

LTE: LTE/3G/2G

WiFi: 802.11 a/b/g/n/ac (2.4/5Ghz)

Bluetooth: BT 4.2+BLE

GNSS: GPS+AGPS, GLONASS, QZSS

CPU: Qualcomm SDM 450

Memory Storage: 4GB / 64GB, microsSD Expansion

Display: 7”, 600x 1024 pixels

Touchscreen: Anti-glare, Capacitative, Multi-point

Battery: 4,000mAh Li-ion Polymer, Battery life 8+ hours depending on usage

Operational Voltage: 9˜32V wide DC input

Current Consumption at 12V: Awake, idle ~250mA, Battery Charging ~1A

Cameras: Front: 8MP AF, Rear: 8MP AF with Flash

Microphone, Speaker: 2x Built-in microphones, 1x Built-in speaker

I/O Ports: 6-pin fleet port (Tx/Rx, 12/24V, IGN), Type C USB 2.0 port

Sensors: NFC sensor, Light sensor

Operating Temperature: -20°C to +60°C (-4° to +140°F) operating

Size: Height: 5.19", Width: 8.29", Depth: 0.8"

Weight: 16.9oz

Firmware Updates: Over-the-air (OTA)

Supported Platforms: DIRECTOR, TN360



Easy Docs: Electronic documents available 24/7 – reduce the paperwork required to be stored in the vehicle.

Messaging: Instant driver-dispatch communication and manager-based routing messages for immediate in-cab updates.

Journey Planner (including SmartNav Route): Create smarter, more specific routes that include all scheduled stops and waypoints and provide drivers with turn-by-turn navigation to their destination following the specified route.

Forms: Paperless, customizable forms for receiving & tracking information across the business in real-time.

Pre-trip Checklist: Create any number of checklists for driver and vehicle safety and compliance.

Driver Scorecard: Keep an eye on driver performance and safety via a number of metrics.

Comprehensive application suite that offers users a variety of advanced in-vehicle apps.

ELD - Federally compliant Hours of Service electronic logging devices (ELD)

DVIR - Driver Vehicle Inspection Reports

Navigation - Voice activated navigation and routing w/ vehicle profile

Instant Messaging - Driver to base instant messaging communication

Forms - Digitized forms for tracking job information, as well as capturing signatures

EMS - Provides insight into engine performance, like speed and temp
