Satellite Communications
Dependable Comms for Your Drivers and Assets No Matter Where They Are
While the cellular network is vastly improving, your teams might not always work in areas with strong signal, causing a delay in data transfer. This can become an issue for workforces and assets operating in remote locations, when knowing their location is highly important for safety and duty of care.
Teletrac Navman’s Satellite Communications solutions ensures that you always have the visibility you need. The platform extends connectivity beyond cellular limits by using the satellite communications network to share prioritized data without delay.
While traditional satellite communication platforms were expensive, the Teletrac Navman solution allows for communication costs to be easily managed and data to be prioritized, so you only use the satellite network for time sensitive information.
Key Features
- Access to the satellite network via the internal Iridium SBM Modem for lower latency and superior network capabilities.
- Paired with vehicle telematics and an external antenna for improved communications when line of site is compromised.
- Get alerts on location, duress, roll over, impact and tow away.
- Activity logging for events such as health checks, ignition status, geofence, and driver behavior metrics, like harsh usage, roll over and over rev.
- Reporting for visibility into how each asset is utilized, and the activities undertaken, including summary, alarm, and distance trip reports.
- Receive GPIO digital input alerts and reporting, such as duress buttons or seatbelt monitoring.
Satellite Network
Ruggedized Casing
Data Prioritization
Network Roaming
Technical Specifications
See why this device is right for you
Certifications: US (FCC), EU (CE Mark), RoHS Compliant, FCC, IC, CE, Iridium® Satellite Network Certification
Environmental: SAE J1455
Ratings: IP67
Input / Output:Primary 10-way Serial, Secondary 18-way Serial
Interfaces: AT+ Command, RS232
Connectivity: Iridium SBM Modem
Frequency: 1616-1626.5 MHz
SBD Transceiver: Iridium 9602N
Antenna: External, Integrated Iridium Certified Antenna
Supply Voltage: 9 - 32V, maximum 1.6W
Current Consumption (Average):
Power On Max Current 0.5A
Operational Max Current 0.3A
Low Power Modes: < 200uA
Reverse Polarity Protection: Yes
Size:
Height: 39mm
Width: 80mm
Depth: 130mm
Weight: 320g
Tracking: 60 minute timed updates, can be set to 30 minutes
Operating Temperature: -40ºC to +80ºC
Storage Temperature: -40ºC to +85ºC
